Antenna connector type | RP-SMA |
Antenna type | External |
Antennas quantity | 2 |
Certification | CE, FCC |
Colour of product | Green |
Compatibility | PC |
Compatible operating systems | Windows 7 (32/64-bits) Windows Vista (32/64-bits) Windows XP (32/64-bits) |
Compliance industry standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Connectivity technology | Wireless |
Data transfer rate (max) | 300 Mbit/s |
Depth | 120.8 mm |
Frequency band | 2.400 - 2.4835 GHz |
Gain | 2 dBi |
Height | 78.5 mm |
Host interface | PCI-E |
Interface | WLAN |
Internal | Yes |
LED indicators | Yes |
Mac compatibility | No |
Manual | Yes |
Minimum system requirements | PCI-E x1 |
Modulation | 16-QAM,64-QAM,DBPSK,DQPSK,OFDM |
Networking standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Operating relative humidity (H-H) | 10 - 90 % |
Operating relative humidity range | 10 - 90 % |
Operating temperature (T-T) | 32 - 104 °F |
Quick start guide | Yes |
Receiver sensitivity | 270M: -68dBm@10% 130M: -68dBm@10% 108M: -73dBm@10% 54M: -73dBm@10% 11M: -89dBm@8% 6M: -87dBm@10% 1M: -90dBm@8% |
RoHS compliance | Yes |
Security algorithms | 128-bit WEP,64-bit WEP,WPA-PSK,WPA2-PSK,WPS |
Security algorithms supported | 128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS |
Source data-sheet | Icecat.biz |
Storage relative humidity (H-H) | 5 - 90 % |
Storage relative humidity range | 5 - 90 % |
Storage temperature (T-T) | -40 - 70 °C |
Storage temperature range (T-T) | -40 - 70 °C |
Wi-Fi | Yes |
Wi-Fi standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Width | 21.5 mm |
Windows operating systems supported | Yes |
Wireless LAN connection | Yes |
Wireless LAN type | 802.11b, 802.11g, 802.11n |
WLAN data transfer rates supported | 11,54,150,300 Mbit/s |
