AC outlet types | C13 coupler |
AC outlets quantity | 6 AC outlet(s) |
Battery capacity | 328 VAh |
Battery recharge time | 3 h |
Battery technology | Sealed Lead Acid (VRLA) |
Cables included | RS-232 |
Certification | C-tick, CE, EN 50091-1, EN 50091-2, EN 60950, EN 61000-3-2, GOST, VDE |
Colour of product | Black |
Crest factor | 3:1 |
Depth | 483 mm |
Efficiency | 88.9 % |
Form factor | Rackmount/Tower |
Height | 85 mm |
Hot-swap battery | Yes |
Input operation voltage (max) | 280 V |
Input operation voltage (min) | 100 V |
International Protection (IP) code | IP20 |
LED indicators | Status |
Manual | Yes |
Noise level | 50 dB |
Non-operating altitude | 0 - 15000 m |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 0 - 95 % |
Operating temperature (T-T) | 0 - 40 °C |
Output operation voltage (max) | 240 V |
Output operation voltage (min) | 220 V |
Output power | 700 W |
Package height | 286 mm |
Package weight | 27800 g |
Package width | 630 mm |
Power supply input frequency | 50/60 Hz |
Quantity per pallet | 4 pc(s) |
Rack mounting | Yes |
RoHS compliance | Yes |
Storage relative humidity (H-H) | 0 - 95 % |
Storage temperature (T-T) | -20 - 50 °C |
Surge energy rating | 420 J |
Typical backup time at full load | 13.8 min |
Typical backup time at half load | 32 min |
Waveform | Sine |
Weight | 23000 g |
Width | 432 mm |
