AC input frequency | 50/60 Hz |
AC input voltage | 100-240 V |
Bandwidth | 16 Gbit/s |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Bundled software | Cisco IOS LAN Lite |
Colour of product | Black |
Depth | 242 mm |
Flash memory | 64 MB |
Flow control support | Yes |
Full duplex | Yes |
Height | 44 mm |
Internal memory | 128 MB |
LED indicators | Yes |
MAC address filtering | Yes |
Manual | Yes |
Mean time between failures (MTBF) | 667 h |
Memory type | DRAM |
MIB support | Yes |
Networking standards | IEEE 802.1p,IEEE 802.1x |
Noise level | 33 dB |
Non-operating altitude | 0 - 4000 m |
Number of VLANs | 64 |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 10 - 95 % |
Operating relative humidity range | 10 - 95 % |
Operating temperature (T-T) | -5 - 40 °C |
Power consumption (typical) | 18.6 W |
Power LED | Yes |
Quality of Service (QoS) support | Yes |
Security algorithms | 802.1x RADIUS |
Security algorithms supported | 802.1x RADIUS |
Stackable | No |
Storage relative humidity (H-H) | 10 - 95 % |
Storage relative humidity range | 10 - 95 % |
Storage temperature (T-T) | -25 - 70 °C |
Storage temperature range (T-T) | -25 - 70 °C |
Switch layer | L2 |
Switch type | Managed |
Throughput | 6.5 mpps |
User guide | Yes |
Web-based management | Yes |
Weight | 3600 g |
Width | 450 mm |
