More Info
Details

The HP 3800 Switch Series is a family of fully managed Gigabit Ethernet switches. There are a total of nine switch models—a 24-port switch, a 48-port switch, a 24-port PoE+ switch, a 48-port PoE+ switch

with either SFP+ or 10GBASE-T uplinks, and a 24-portSFP switch with 2 SFP+ uplinks. HP 3800 Series Switches utilize the latest HP ProVision ASIC technology and combine the latest advances in hardware engineering to deliver one of the most resilient and energy-efficient switches in the industry.

The 3800 series implements meshed stacking technology to deliver chassis-like resiliency in a flexible stackable form factor.

10G support	Yes
Authentication method	IEEE 802.1X, RADIUS, MAC
Auto MDI/MDI-X	Yes
Basic switching RJ-45 Ethernet ports quantity	48
Built-in processor	HP ProVision ASIC/ARM 350 Mhz & Freescale PowerPC 1200 MHz
Certification	FCC Class A, VCCI Class A, EN 55022/CISPR 22 Class A
Colour of product	Grey
Connectivity technology	Wired
Copper ethernet cabling technology	1000BASE-T,100BASE-TX,10BASE-T,10GBASE-T
DHCP client	Yes
DHCP server	Yes
Dimensions (WxDxH)	467.4 x 442.7 x 43.2 mm
Drive device, buffer size	36 MB
Ethernet LAN (RJ-45) ports quantity	48
Firmware upgradeable	Yes
Flash memory	4096 MB
Form factor	19"
Full duplex	Yes
Gigabit Ethernet (copper) ports quantity	48
Heat dissipation	635 BTU/h
Input current	9.4 - 7.8 A
Input frequency	50 - 60 Hz
Input voltage	100 - 240 V
Installed ports	52
Internal memory	2048 MB
Latency	1.9µs
MAC address table	65500 entries
Management platform	SNMP, Telnet, Web
Management protocols	SNMP v3
Maximum data transfer rate	10000 Gbit/s
Memory type	SDRAM
MIB support	Yes
Mounting	1U
Networking features	Gigabit Ethernet, 10G Ethernet
Number of power supply units	1
Number of VLANs	2048
Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	15 - 95 %
Operating relative humidity range	15 - 95 %
Operating temperature (T-T)	0 - 55 °C
Operating temperature range (T-T)	0 - 55 °C
Packet buffer memory	36 MB
Ports quantity	52
Power consumption (typical)	130 W
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) support	Yes
Power supply	1000 W
Power supply type	HP X312
Quality of Service (QoS) support	Yes
Rack mounting	Yes
Redundant power supply (RPS) support	Yes
Safety	EN 60950/IEC 60950, UL 60950, CAN/CSA 22.2 No. 60950, EN 60825
Security algorithms	802.1x RADIUS,SSH,SSL/TLS
Security algorithms supported	802.1x RADIUS, SSH, SSL/TLS
Security features	CLI, GUI, MIB
Source data-sheet	Icecat.biz
Spanning tree protocol	Yes
Stackable	Yes
Storage relative humidity (H-H)	15 - 90 %
Storage temperature (T-T)	-40 - 70 °C
Storage temperature range (T-T)	-40 - 70 °C
Supported data transfer rates	10/100/1000 Mbps
Switch layer	L3
Switch type	Managed
Switching capacity	176 Gbit/s
Web-based management	Yes
Weight	7820 g
Wi-Fi	No
Wireless LAN connection	No

Similar products

TP-LINK 8-port 10/100 Unmanaged PoE Switch
TP-LINK TL-SF1005D
TP-LINK 8-Port 10/100Mbps Desktop Switch
TP-LINK TL-SG1008
TP-LINK TL-SM311LS

Hewlett Packard Enterprise 3800-48G-PoE+-4XG

Managed, 48 x RJ-45, 10/100/1000 Mbps, 4 x RJ-45 10GbE, 1 x RJ-45 Console, HP ProVision ASIC/ARM 350 MHz, Freescale PowerPC 1200 MHz, 4GB Flash, Buffer 36 MB, 2GB SDRAM, RADIUS/TACACS+, SSHv2, SSL, 48.26 cm (19 ") , PoE, 186W, 7.82kg

Reference: J9588A

Stock Due 01-02-2025

£11,211.22

£9,342.68 Ex VAT.
